hy16
hy16-1 long-range illuminator
Hybrid Low Voltage
VARIO2 low voltage, short, medium and long-range Hybrid illuminators
About VARIO2 Standard – Hybrid
- Sector
- Security
- Wavelength
- Infra-Red 850nm & White-Light
The awarding-winning VARIO2 Hybrid LED illuminators deliver all the performance of a stand-alone Infra-Red and a stand-alone White-Light illuminator in a single, fully integrated two-in-one solution. The range is made up of a number of sizes designed to cover short, medium and long-range distances. VARIO2 delivers world-leading power and illumination distances which can improve the performance of any video surveillance system at night.
Jump to Downloads
All-in-One Solution.
VARIO2 Hybrid LED illuminators deliver all the performance of a stand-alone Infra-Red and a stand-alone White-Light illuminator in a single, fully integrated two-in-one solution.
Outstanding Distances.
Hybrid delivers distances of up to 450m (1476ft) of Infra-Red illumination and 195m (640ft) of White-Light illumination - all from a single illuminator.
Hot-spot Reduction Technology.
A highly diffused, elliptical beam shape delivers more light where it's needed; minimising light wastage and preventing overexposure of foreground objects
VARIO Remote Control.
Angles from 10-120°.
Interchangeable Lenses.
VARIO2 VARIANTS.
VARIO2 Hybrid illuminators are available in a range of different sizes to suit different applications and requirements.
hy8
hy8-1 long-range illuminator
hy6
hy6-1 medium-range illuminator
hy4
hy4-1 medium-range illuminator
Specs
Select Option
| HY4 | HY6 | HY8 | HY16 | |
|---|---|---|---|---|
| Wavelength | Infra-Red 850nm & White-Light | |||
| Max Distance (IR) | 130m (427ft) | 180m (591ft) | 290m (951ft) | 450m (1476ft) |
| Max Distance (WL) | 70m (230ft) | 88m (289ft) | 144m (472ft) | 195m (640ft) |
| Total Lumens (WL) | 745lm | 1490lm | 2981lm | 5692lm |
| CRI (WL) | >70 | |||
| Colour Temp (WL) | 6000K~ | |||
| Angle | Standard pack includes 10° circular + 35° x 10° (fitted as standard) and 60° x 25°elliptical lenses. Additional optional lenses: 80° x 30°, 120° x 50° | |||
| Input | 24V DC | |||
| Consumption | 13W | 21W | 40W | 78W |
| Beam Shape | Elliptical with HRT (Hot-spot Reduction Technology) | |||
| Number of LEDs | 9 (6 x IR and 3 x WL) | 12 (6 x IR and 6 x WL) | 24 (12 x WL and 12 x IR) | 48 (24 x IR and 24 x WL) |
| IP Rating | IP66 | |||
| Temperature Range | -50° to +50°C (-58 to 122°F) | |||
| Weight | 950g (2.1lbs) | 950g (2.1lbs) | 1.6kg (3.6lbs) | 3.1kg (6.8lbs) |
| Cable Length | 2.5m | |||
| Cable Specification | Red/Black - Power, White/Yellow - Photocell following output, Orange/ Purple - Telemetry input | |||
| Bracketry | U bracket included (VUB Bracketry also available) | |||
Product Dimensions.
HY16
VARIO2 IP PoE hy8
VARIO2 IP PoE hy4 & hy6Downloads.
Datasheet - VARIO2 Hybrid Installation Instructions - VARIO2 Hybrid Datasheet - VARIO PSU User Guide - VARIO2 Remote Control Bracket Guide - VARIO Universal Bracket (VUB) A&E Specifications - VARIO2 Hybrid
